They're bit-fields, an example being that unsigned int addr:9; creates an addr field 9 bits long.
It's commonly used to pack lots of values into an integral type. In your particular case, it defining the structure of a 32-bit microcode instruction for a (possibly) hypothetical CPU (if you add up all the bit-field lengths, they sum to 32).
The union allows you to load in a single 32-bit value and then access the individual fields with code like (minor problems fixed as well, specifically the declarations of code and test):
#include <stdio.h>
struct microFields {
unsigned int addr:9;
unsigned int cond:2;
unsigned int wr:1;
unsigned int rd:1;
unsigned int mar:1;
unsigned int alu:3;
unsigned int b:5;
unsigned int a:5;
unsigned int c:5;
};
union micro {
unsigned int microCode;
struct microFields code;
};
int main (void) {
int myAlu;
union micro test;
test.microCode = 0x0001c000;
myAlu = test.code.alu;
printf("%d\n",myAlu);
return 0;
}
This prints out 7, which is the three bits making up the alu bit-field.
syntax - Use of the : operator in C - Stack Overflow
I still don't understand the difference between "&" and "*" in C.
What is the '-->' operator in C/C++? - Stack Overflow
microcontroller - What do the C operators "&=" and "|=" do? - Electrical Engineering Stack Exchange
Videos
They're bit-fields, an example being that unsigned int addr:9; creates an addr field 9 bits long.
It's commonly used to pack lots of values into an integral type. In your particular case, it defining the structure of a 32-bit microcode instruction for a (possibly) hypothetical CPU (if you add up all the bit-field lengths, they sum to 32).
The union allows you to load in a single 32-bit value and then access the individual fields with code like (minor problems fixed as well, specifically the declarations of code and test):
#include <stdio.h>
struct microFields {
unsigned int addr:9;
unsigned int cond:2;
unsigned int wr:1;
unsigned int rd:1;
unsigned int mar:1;
unsigned int alu:3;
unsigned int b:5;
unsigned int a:5;
unsigned int c:5;
};
union micro {
unsigned int microCode;
struct microFields code;
};
int main (void) {
int myAlu;
union micro test;
test.microCode = 0x0001c000;
myAlu = test.code.alu;
printf("%d\n",myAlu);
return 0;
}
This prints out 7, which is the three bits making up the alu bit-field.
It's a bit field. The number after the colon is how many bits each variable takes up.
So I know roughly how pointers work. You have a value, say char x, and doing char* x isn't the actual content of the variable but rather the physical address it's located at.
But the thing that really confuses me is where we use "&" versus "*". I know "&" corresponds to the memory location of something, but isn't that what the pointer operator does? Just gives you the memory address of a variable? When exactly do we use "&" and "*"?
Is the pointer operator just for defining pointer "objects" (in a sense) while the ampersand is done as a way of reading a memory address versus operating with it?
--> is not an operator. It is in fact two separate operators, -- and >.
The code in the condition decrements x, while returning x's original (not decremented) value, and then compares the original value with 0 using the > operator.
To better understand, the statement could be written as follows:
while( (x--) > 0 )
Or for something completely different... x slides to 0.
while (x --\
\
\
\
> 0)
printf("%d ", x);
Not so mathematical, but... every picture paints a thousand words...
These statements are equivalent:
x = x & 0x01;
x &= 0x01;
It means to perform a bitwise operation with the values on the left and right-hand side, and then assign the result to the variable on the left, so a bit of a short form. If you're not familiar with bitwise operations, I suggest you start getting familiar with those first - the & being a bitwise AND and the | being a bitwise OR.
Hope that helps!
&= is and equals, |= is or equals. These perform bit-wise operations with the left hand and right hand arguments, and assign the result into the left hand side.
