The D-shaped shell provides automatic polarization as it only fits one way. EDAC offers a slim VGA with vertical pins but side cable entry that saves up to 70% board space! The DB15 connector is an analog socket, with 15 pins, from the D-Subminiatures (D-Sub) connector family.
NorComp
norcomp.net › products › db15-connector › 279
DB15 Connector | 15 Pin D-Sub Connector
For a pin configuration of three rows of slightly offset and more densely located 5 pin rows, an “E” shell size is used. It results in a DE15 high-density connector. However, since early personal computers switched from using the common DB25 connectors to other sizes and forms of connectors, many people confused the D-sub title with the DB title. For this reason, the DB15 connector is still commonly understood in the industry to be synonymous with either a DA15 or DE15 connector.
