Possibly yes. That IDC connector is basically just the same electrical connections but just in a compact connector for motherboard connection use. Just look at this image taken from this Amazon listing for a, StarTech USB A to USB Motherboard 4-Pin Header F/F 2.0 Cable, 6" (USBMBADAPT):
Note the exposed wires as well as the text on the motherboard header connector. That’s your big clue! So basically if you wanted to clip off the connectors on your device and wire them to a male USB that could be done as long as you match data and power wires correctly.
And if you are afraid of doing that yourself, you could purchase this: “Adapter Cable, USB 2.0, IDC 5 Male (single row) to USB A Male”:
And as the description for the product states:
Used to connect devices designed to plug into USB motherboard header pins to an external USB 2.0 connector
That’s actually a neat tool because you can now use the device as you wish without having to mangle the cable; just plug the female IDC connector into the male IDC connector and bingo! You have a USB device.
But since your device has 10 connectors you would need two of those cables to make that reader fully work. It could be that one connector has certain media reader slots and the other handles others; so maybe scoring one cable and experimenting might be the way to go.
EDIT: An addition, but here is a cool image of how someone was able to use one of those male male IDC motherboard header connector cables to connect to a USB flash drive with a broken connector. This shows clearly what all 5 connectors are: 2 are data, 2 are power and 1 is for the grounding/shielding.
Can a DB9 connector be used as a usb connector
Any recommendations for a 9-pin joystick to USB adaptor?
*Need* an additional 9 pin USB header, solutions?
Can you recommend a 9 pin to USB controller adapter
Videos
Possibly yes. That IDC connector is basically just the same electrical connections but just in a compact connector for motherboard connection use. Just look at this image taken from this Amazon listing for a, StarTech USB A to USB Motherboard 4-Pin Header F/F 2.0 Cable, 6" (USBMBADAPT):
Note the exposed wires as well as the text on the motherboard header connector. That’s your big clue! So basically if you wanted to clip off the connectors on your device and wire them to a male USB that could be done as long as you match data and power wires correctly.
And if you are afraid of doing that yourself, you could purchase this: “Adapter Cable, USB 2.0, IDC 5 Male (single row) to USB A Male”:
And as the description for the product states:
Used to connect devices designed to plug into USB motherboard header pins to an external USB 2.0 connector
That’s actually a neat tool because you can now use the device as you wish without having to mangle the cable; just plug the female IDC connector into the male IDC connector and bingo! You have a USB device.
But since your device has 10 connectors you would need two of those cables to make that reader fully work. It could be that one connector has certain media reader slots and the other handles others; so maybe scoring one cable and experimenting might be the way to go.
EDIT: An addition, but here is a cool image of how someone was able to use one of those male male IDC motherboard header connector cables to connect to a USB flash drive with a broken connector. This shows clearly what all 5 connectors are: 2 are data, 2 are power and 1 is for the grounding/shielding.
Just for anyone looking for a way to do it:
Thanks to
I managed to get the cables right. As soon as I plugged windows started installing various generic drivers... YAY!!! Here's what I got:
But now Usb doesn't work and I cannot find the right slot for Mini Usb....
For a keyboard build iam looking at different connectors I like the look of an db9 connector. Can I use this instead of a usb connector. So the protocol will be usb, cable will also be usb. I'll snip the usb type a of and replace it with a db9 and do this on the keyboard side to. Will this matter For the signal?
I see one on monsterjoysticks.com and i used to see them on eBay but i don't seem to see them anymore. I'm sure there's many 'retro' dealers out there that sell them so i'd love to hear about them.
I'd like to use my ZipStick on the Nvidia Shield. :)
Thanks? :)
