They're bit-fields, an example being that unsigned int addr:9; creates an addr field 9 bits long.
It's commonly used to pack lots of values into an integral type. In your particular case, it defining the structure of a 32-bit microcode instruction for a (possibly) hypothetical CPU (if you add up all the bit-field lengths, they sum to 32).
The union allows you to load in a single 32-bit value and then access the individual fields with code like (minor problems fixed as well, specifically the declarations of code and test):
#include <stdio.h>
struct microFields {
unsigned int addr:9;
unsigned int cond:2;
unsigned int wr:1;
unsigned int rd:1;
unsigned int mar:1;
unsigned int alu:3;
unsigned int b:5;
unsigned int a:5;
unsigned int c:5;
};
union micro {
unsigned int microCode;
struct microFields code;
};
int main (void) {
int myAlu;
union micro test;
test.microCode = 0x0001c000;
myAlu = test.code.alu;
printf("%d\n",myAlu);
return 0;
}
This prints out 7, which is the three bits making up the alu bit-field.
They're bit-fields, an example being that unsigned int addr:9; creates an addr field 9 bits long.
It's commonly used to pack lots of values into an integral type. In your particular case, it defining the structure of a 32-bit microcode instruction for a (possibly) hypothetical CPU (if you add up all the bit-field lengths, they sum to 32).
The union allows you to load in a single 32-bit value and then access the individual fields with code like (minor problems fixed as well, specifically the declarations of code and test):
#include <stdio.h>
struct microFields {
unsigned int addr:9;
unsigned int cond:2;
unsigned int wr:1;
unsigned int rd:1;
unsigned int mar:1;
unsigned int alu:3;
unsigned int b:5;
unsigned int a:5;
unsigned int c:5;
};
union micro {
unsigned int microCode;
struct microFields code;
};
int main (void) {
int myAlu;
union micro test;
test.microCode = 0x0001c000;
myAlu = test.code.alu;
printf("%d\n",myAlu);
return 0;
}
This prints out 7, which is the three bits making up the alu bit-field.
It's a bit field. The number after the colon is how many bits each variable takes up.
I still don't understand the difference between "&" and "*" in C.
What is the '-->' operator in C/C++? - Stack Overflow
microcontroller - What do the C operators "&=" and "|=" do? - Electrical Engineering Stack Exchange
Pointers in C: when to use the ampersand and the asterisk? - Stack Overflow
Videos
So I know roughly how pointers work. You have a value, say char x, and doing char* x isn't the actual content of the variable but rather the physical address it's located at.
But the thing that really confuses me is where we use "&" versus "*". I know "&" corresponds to the memory location of something, but isn't that what the pointer operator does? Just gives you the memory address of a variable? When exactly do we use "&" and "*"?
Is the pointer operator just for defining pointer "objects" (in a sense) while the ampersand is done as a way of reading a memory address versus operating with it?
--> is not an operator. It is in fact two separate operators, -- and >.
The code in the condition decrements x, while returning x's original (not decremented) value, and then compares the original value with 0 using the > operator.
To better understand, the statement could be written as follows:
while( (x--) > 0 )
Or for something completely different... x slides to 0.
while (x --\
\
\
\
> 0)
printf("%d ", x);
Not so mathematical, but... every picture paints a thousand words...
These statements are equivalent:
x = x & 0x01;
x &= 0x01;
It means to perform a bitwise operation with the values on the left and right-hand side, and then assign the result to the variable on the left, so a bit of a short form. If you're not familiar with bitwise operations, I suggest you start getting familiar with those first - the & being a bitwise AND and the | being a bitwise OR.
Hope that helps!
&= is and equals, |= is or equals. These perform bit-wise operations with the left hand and right hand arguments, and assign the result into the left hand side.
You have pointers and values:
int* p; // variable p is pointer to integer type
int i; // integer value
You turn a pointer into a value with *:
int i2 = *p; // integer i2 is assigned with integer value that pointer p is pointing to
You turn a value into a pointer with &:
int* p2 = &i; // pointer p2 will point to the integer i
Edit:
In the case of arrays, they are treated very much like pointers. If you think of them as pointers, you'll be using * to get at the values inside of them as explained above, but there is also another, more common way using the [] operator:
int a[2]; // array of integers
int i = *a; // the value of the first element of a
int i2 = a[0]; // another way to get the first element
To get the second element:
int a[2]; // array
int i = *(a + 1); // the value of the second element
int i2 = a[1]; // the value of the second element
So the [] indexing operator is a special form of the * operator, and it works like this:
a[i] == *(a + i); // these two statements are the same thing
There is a pattern when dealing with arrays and functions; it's just a little hard to see at first.
When dealing with arrays, it's useful to remember the following: when an array expression appears in most contexts, the type of the expression is implicitly converted from "N-element array of T" to "pointer to T", and its value is set to point to the first element in the array. The exceptions to this rule are when the array expression appears as an operand of either the & or sizeof operators, or when it is a string literal being used as an initializer in a declaration.
Thus, when you call a function with an array expression as an argument, the function will receive a pointer, not an array:
int arr[10];
...
foo(arr);
...
void foo(int *arr) { ... }
This is why you don't use the & operator for arguments corresponding to "%s" in scanf():
char str[STRING_LENGTH];
...
scanf("%s", str);
Because of the implicit conversion, scanf() receives a char * value that points to the beginning of the str array. This holds true for any function called with an array expression as an argument (just about any of the str* functions, *scanf and *printf functions, etc.).
In practice, you will probably never call a function with an array expression using the & operator, as in:
int arr[N];
...
foo(&arr);
void foo(int (*p)[N]) {...}
Such code is not very common; you have to know the size of the array in the function declaration, and the function only works with pointers to arrays of specific sizes (a pointer to a 10-element array of T is a different type than a pointer to a 11-element array of T).
When an array expression appears as an operand to the & operator, the type of the resulting expression is "pointer to N-element array of T", or T (*)[N], which is different from an array of pointers (T *[N]) and a pointer to the base type (T *).
When dealing with functions and pointers, the rule to remember is: if you want to change the value of an argument and have it reflected in the calling code, you must pass a pointer to the thing you want to modify. Again, arrays throw a bit of a monkey wrench into the works, but we'll deal with the normal cases first.
Remember that C passes all function arguments by value; the formal parameter receives a copy of the value in the actual parameter, and any changes to the formal parameter are not reflected in the actual parameter. The common example is a swap function:
void swap(int x, int y) { int tmp = x; x = y; y = tmp; }
...
int a = 1, b = 2;
printf("before swap: a = %d, b = %d\n", a, b);
swap(a, b);
printf("after swap: a = %d, b = %d\n", a, b);
You'll get the following output:
before swap: a = 1, b = 2 after swap: a = 1, b = 2
The formal parameters x and y are distinct objects from a and b, so changes to x and y are not reflected in a and b. Since we want to modify the values of a and b, we must pass pointers to them to the swap function:
void swap(int *x, int *y) {int tmp = *x; *x = *y; *y = tmp; }
...
int a = 1, b = 2;
printf("before swap: a = %d, b = %d\n", a, b);
swap(&a, &b);
printf("after swap: a = %d, b = %d\n", a, b);
Now your output will be
before swap: a = 1, b = 2 after swap: a = 2, b = 1
Note that, in the swap function, we don't change the values of x and y, but the values of what x and y point to. Writing to *x is different from writing to x; we're not updating the value in x itself, we get a location from x and update the value in that location.
This is equally true if we want to modify a pointer value; if we write
int myFopen(FILE *stream) {stream = fopen("myfile.dat", "r"); }
...
FILE *in;
myFopen(in);
then we're modifying the value of the input parameter stream, not what stream points to, so changing stream has no effect on the value of in; in order for this to work, we must pass in a pointer to the pointer:
int myFopen(FILE **stream) {*stream = fopen("myFile.dat", "r"); }
...
FILE *in;
myFopen(&in);
Again, arrays throw a bit of a monkey wrench into the works. When you pass an array expression to a function, what the function receives is a pointer. Because of how array subscripting is defined, you can use a subscript operator on a pointer the same way you can use it on an array:
int arr[N];
init(arr, N);
...
void init(int *arr, int N) {size_t i; for (i = 0; i < N; i++) arr[i] = i*i;}
Note that array objects may not be assigned; i.e., you can't do something like
int a[10], b[10];
...
a = b;
so you want to be careful when you're dealing with pointers to arrays; something like
void (int (*foo)[N])
{
...
*foo = ...;
}
won't work.
