Hi @rer97391 · Try a full power refresh and check if that fixes it. · Disconnect the power from the PC. · Open the case and then locate and remove the RTC coin cell battery¹ from the motherboard. · Go to p.35 (39 of 68 pdf) of the hardware maintenance manual to view the procedure to remove/replace the coin cell battery from the motherboard · Press and hold the PC Power On button operated for a full 30 seconds and then release it. · Reinsert the RTC coin cell battery (+ve on top as marked on the battery), reassemble the PC, connect power to the PC and check if it turns on OK and you can get into BIOS or if the error is still there. · If it turns on there may be a message stating that the Date and Time are incorrect. This is normal as the BIOS has been reset by the above procedure. Once the Date and Time have been corrected, the message won't appear the next time the PC is started. · ¹ When the RTC coin cell battery is out, measure its voltage. If it is <2.5V DC or if the battery is >4-5 years old, replace it. The battery model number is on the battery e.g. CR2032. If it is a CR2032, these are commonly available everywhere, e.g. supermarkets. Answer from jayeff on ifixit.com
Top answer 1 of 2
2
Hi @rer97391 · Try a full power refresh and check if that fixes it. · Disconnect the power from the PC. · Open the case and then locate and remove the RTC coin cell battery¹ from the motherboard. · Go to p.35 (39 of 68 pdf) of the hardware maintenance manual to view the procedure to remove/replace the coin cell battery from the motherboard · Press and hold the PC Power On button operated for a full 30 seconds and then release it. · Reinsert the RTC coin cell battery (+ve on top as marked on the battery), reassemble the PC, connect power to the PC and check if it turns on OK and you can get into BIOS or if the error is still there. · If it turns on there may be a message stating that the Date and Time are incorrect. This is normal as the BIOS has been reset by the above procedure. Once the Date and Time have been corrected, the message won't appear the next time the PC is started. · ¹ When the RTC coin cell battery is out, measure its voltage. If it is <2.5V DC or if the battery is >4-5 years old, replace it. The battery model number is on the battery e.g. CR2032. If it is a CR2032, these are commonly available everywhere, e.g. supermarkets.
2 of 2
1
On a Lenovo ThinkCentre M920q, a 3 long, 1 short beep usually indicates a memory or motherboard fault. Since a new DDR4 SODIMM didn’t fix it, try this: · Reseat the RAM firmly and test one stick at a time in each slot. · Clear CMOS (remove the coin-cell battery for 5–10 minutes). · Check for bent pins, debris, or damage on the board. · Ensure the correct 65W/90W Lenovo power adapter is used. · If the beeps persist and there’s no display or BIOS access, the motherboard is likely faulty. Given the $4 purchase, board replacement may cost more than it’s worth.
Lenovo Support
support.lenovo.com › us › en › solutions › ht505216-post-beep-symptoms-thinkcentre
Beep symptoms during startup – ThinkCentre - Lenovo Support US
This article shows you solutions to resolve POST Beep symptoms for ThinkCentre
Videos
r/pchelp on Reddit: 3 short 1 long beep. Hardware issue (I believe)
r/computers on Reddit: 3 short then 1 long beep
r/Lenovo on Reddit: 3 beeps short 1 long
r/Lenovo on Reddit: What could this beep code mean?
03:13
Lenovo PC Continuous Beep and No Display After Turn On PC - How ...
Lenovo Desktop Thinkstation Beep Error (3 short beeps 1 long ...
Reddit
reddit.com › r/sysadmin › lenovo m93p - 3 short beeps followed by 1 long beep.
r/sysadmin on Reddit: Lenovo m93p - 3 short beeps followed by 1 long beep.
February 23, 2023 -
Has anyone experienced any issues with these desktops suddenly failing to boot?
I have 2 that have displayed this issue within a week of each other.
Manual has:
BEEP SYMPTOM - 3 short beeps followed by 1 long beep.
BEEP MEANING - Memory not detected.
SUGGESTED ACTIONS - Investigate memory subsystem. Ensure that any memory module(s) are properly seated in the connectors.
I have tried new ram and different slots.
I am suspicious of an update that has broken the firmware.
Lenovo Community
forums.lenovo.com › t5 › ThinkCentre-A-E-M-S-Series › 3-Short-and-1-Long-beep › m-p › 4427818
3-Short-and-1-Long-beep - English Community - LENOVO COMMUNITY
I have Dual Channel RAM DIMMs, so I just installed a new module into the same color of the other ram, but after I boot it, I got 3 short and 1 long beep. PLEASE HELP. My PC is Lenovo ThinkCentre M82 (Small Form Factor) ... That beep code indicates a DRAM error.
Quora
quora.com › Why-does-my-Lenovo-Thinkcentre-PC-CPU-make-4-beeps-short-short-short-long-continuously-whenever-I-try-to-boot-it-it-does-not-start
Why does my Lenovo Thinkcentre PC CPU make 4 beeps (short, short, short, long) continuously whenever I try to boot it (it does not start)? - Quora
Answer: That beeping is called as POST(power-on self-test) check. The 3 short 1 long beep indicates usually indicates ‘extended memory failure’ specific to IBM it indicates video card issue sometimes Any kind of beep except single beep is hardware failure.
Reddit
reddit.com › r/lenovo › lenovo thinkcentre m920z 3 long 1 short beeps
r/Lenovo on Reddit: Lenovo ThinkCentre M920z 3 long 1 short beeps
April 19, 2024 -
Hello to you good sirs and madames!
I have strange not-consistent problem. ThinkCentre M920z doesn't boot most of the times (sometimes it boots and I can't find any reasonable pattern). When in doesn't boot, it gives 3 long and 1 short beeps (sometimes it makes 3 long 1 short 3 long 1 short). It is not RAM problem (3 short 1 long) as far as I concerned. Tried searching web, there are some topics about this beep code, but no solutions and answers for what it could be (only assumptions it's either CPU or Motherboard).
Any suggestions or help would be appriciated! Thanks in advance!
P.S. Sorry for any mistakes - english is not my first language.
Top answer 1 of 3
1
Additional information I got while trying to find some patterns. If RAM is installed in DIMM1 port - beeps comes almost immideatly after start. If RAM is installed in DIMM2 slot - beeps come after 10-15 seconds. Also, not sure, but looks like it can sometimes boot if it is cold. I went to eat and when come back - it menaged to boot one time. I run some test (with built-in Lenovo software) - every test passed (cpu and memory test were short, not full). I am running out of any ideas what else to do and check. :c
2 of 3
1
Ok, so just for future generations. Looks like it was corrupted BIOS. Somehow menaged to update BIOS to latest version - problem disappeared. :)
Lenovo Community
forums.lenovo.com › t5 › ThinkCentre-A-E-M-S-Series › Lenovo-m70q-Gen-3-GM0G8ZCB-3-short-beeps-and-1-long-beep-after-Bios-Update › m-p › 5303207
Lenovo-m70q-Gen-3-GM0G8ZCB-3-short-beeps-and-1- ...
April 11, 2024 - Welcome to Lenovo and Motorola community. If the website doesn't work properly without JavaScript enabled. Please enable it to continue
Linus Tech Tips
linustechtips.com › computer hardware › cpus, motherboards, and memory
3 short beeps and 1 long beep. - CPUs, Motherboards, and Memory - Linus Tech Tips
June 19, 2020 - I've had this Lenovo Thinkcentre m82 for over a year now. And it came to thought that why wouldn't I upgrade it. So I bought a Geforce GTX 1050 TI Mini from Zotac and it works perfectly, but the main problem is the RAM I bought. The motherboard I have has dual channel RAMS so it would make sense ...
Lenovo Community
forums.lenovo.com › t5 › ThinkCentre-A-E-M-S-Series › 3-short-beep-1-long › m-p › 5049887
3-short-beep-1-long - English Community
Welcome to Lenovo and Motorola community. If the website doesn't work properly without JavaScript enabled. Please enable it to continue
Lenovo Community
forums.lenovo.com › t5 › ThinkStation-Workstations › 3-Short-Beeps-1-Long-Beep-when-adding-2-32GB-ECC-RAM-to-my-existing-2-16GB-P350-Tower-WS › m-p › 5206437
3-Short-Beeps-1-Long-Beep-when-adding-2-32GB-ECC ...
Welcome to Lenovo and Motorola community. If the website doesn't work properly without JavaScript enabled. Please enable it to continue
Lenovo Community
forums.lenovo.com › t5 › ThinkCentre-A-E-M-S-Series › 3-Long-1-Short-Beep › m-p › 5049337
3-Long-1-Short-Beep
November 13, 2020 - Welcome to Lenovo and Motorola community. If the website doesn't work properly without JavaScript enabled. Please enable it to continue
Lenovo Community
forums.lenovo.com › t5 › Lenovo-Desktop-Towers › 3-Long-beep-1-short › m-p › 5199547
3-Long-beep-1-short - English Community - LENOVO COMMUNITY
It seems that it is the ssd because when I remove the ram it chabges the beep code to 3 short beeps 1 Long which is the memory problem and when I chance the ssd it remains 3 Long beeps 1 short.
Lenovo Support
support.lenovo.com › in › en › solutions › ht505216-post-beep-symptoms-thinkcentre
Beep symptoms during startup – ThinkCentre - Lenovo Support IN
This article shows you solutions to resolve POST Beep symptoms for ThinkCentre
Hardware Centric
hardwarecentric.com › 3-short-beeps-1-long-beep-lenovo
[Fix] 3 Short Beeps 1 Long Beep Lenovo (100% Working)
May 3, 2023 - Welcome to HardwareCentric Solving the Spectrumof Hardware Centric issues in Your PC World Search for solutions… Need Assistance? We’re proud to have been featured by some of the world’s leading organizations. These features highlight our excellence in the field of Electronics Knowledge.
Lenovo Community
forums.lenovo.com › t5 › ThinkCentre-A-E-M-S-Series › 3-Short-and-1-Long-beep › td-p › 4427818
3-Short-and-1-Long-beep - English Community
May 13, 2019 - Welcome to Lenovo and Motorola community. If the website doesn't work properly without JavaScript enabled. Please enable it to continue
Lenovo Community
forums.lenovo.com › t5 › ThinkCentre-A-E-M-S-Series › Fail-to-boot-short-short-short-long-beep-code-after-M92p-BIOS-Update › m-p › 1025369
English Community-Lenovo Community
February 23, 2020 - Welcome to Lenovo and Motorola community. If the website doesn't work properly without JavaScript enabled. Please enable it to continue
JustAnswer
justanswer.com › computer › 5qhav-trying-turn-lenovo-thinkcenter-m58p-tower-when.html
Troubleshooting Lenovo ThinkCentre M58p: Beep Codes and CMOS Issues
October 24, 2011 - ThinkCentre M58p may show 3 beep codes and fast fan spin due to memory or motherboard faults.
Lenovo Community
forums.lenovo.com › t5 › ThinkCentre-A-E-M-S-Series › M900-10FM-Will-not-start-3-long-beeps-then-1-short-beep › m-p › 5358523
M900-10FM-Will-not-start-3-long-beeps-then-1-short-beep
January 20, 2025 - Welcome to Lenovo and Motorola community. If the website doesn't work properly without JavaScript enabled. Please enable it to continue
Reddit
reddit.com › r/lenovo › 3 short beeps, one long. cant find online.
r/Lenovo on Reddit: 3 short beeps, one long. Cant find online.
November 9, 2020 -
Ive had my computer for about 3 1/2 years now. For the last week or so ive been getting the error code 3 short beeps one long and then after a restart it works. Now its doing the same pattern but wont turn on after reboot. I cant find the solution online. What do?
Top answer 1 of 2
1
I solved mine, after testing the ram didnt solve it, I tried a new power supply and now it boots. I think I had too many USB devices running at once and it fried the power adapter, Now I have uprated my power so hopefully doesnt happen again.
2 of 2
1
3 shorts and 1 long is RAM I believe. Have you messed with the ram at all recently? ensure ram modules are seated correctly try removing and reseating try moving into different slots if you have more than one ram stick, one might be broken. Remove one at a time to see if it comes right (the removed one is the broken one) replace ram or borrow someone else’s to confirm before purchasing new ram
